PE pneumatic air hose product characteristics:
1.Through the air, water, oil and other media.
2.It has good chemical stability, oil resistance, water resistance, solvent resistance, etc.
3.Low price is the biggest advantage of PE pneumatic air hose, saving cost.
4.PE pneumatic pipe tube body is smooth, fluid resistance is small.
Matters needing attention:
1.Don't let PE flexible plastic tubing too stretch, bend distortion, otherwise it will make the hose damaged, affecting the work pressure.
2.Pneumatic pipe please be careful for the working environment temperature that is too high (>55 ℃) or chemical gas in the workplace, because it may lead to a hose soften and the pressure resistance drop dramatically.
Model |
Tube Outside diameter(mm) |
Tube |
Length |
The use of pressure(kgf/c㎡) |
Blasting pressure(kgf/c㎡) |
PE-0425-200 |
4 |
2.5 |
200 |
6 |
25 |
PE-0604-200 |
6 |
4 |
200 |
5.5 |
18 |
PE-0805-100 |
8 |
5 |
100 |
6 |
20 |
PE-1065-100 |
10 |
6.5 |
100 |
6 |
18 |
PE-1208-100 |
12 |
8 |
100 |
5.5 |
15 |
|
|
|
|
|
|
